AES EL00W Wired Exit Loop

Wired Vehicle Detection for Easy and Convenient Gate Automation

The AES EL00W Wired Vehicle Detection System is a highly reliable, wired vehicle loop solution designed for high-traffic environments and operational sites. This system offers superior performance with magnetometer sensors that accurately detect vehicles for automatic gate control and other devices. Built for durability and long-lasting operation, the EL00W is perfect for commercial, industrial, and residential applications.

The EL00W is compatible with all gate opener manufacturers, making it an incredibly versatile solution for a wide range of automatic gate systems. Whether you're using it for commercial, industrial, or residential properties, the EL00W integrates seamlessly into your existing setup, offering a reliable and interference-free wired solution.

The system offers two modes: Exit Mode and Presence Mode (available with EL00W-RAD). These modes cater to different operational needs depending on whether you want the system to detect departing vehicles or vehicles that are stationary or moving slowly near the gate.

Understanding Exit Mode and Presence Mode

• Exit Mode: In Exit Mode (EL00W), the loop detects vehicles as they exit the property, automatically triggering the gate to open. This is ideal for environments where you need smooth, hands-free gate operations as vehicles leave without requiring an additional signal. Concealed mounting is an option for Exit Mode, making it a more discreet solution when aesthetics or space are a concern.
• Presence Mode: The Presence Mode (EL00W-RAD) detects vehicles in the path of the gate and ensures the gate remains open as long as a vehicle is present. This is particularly useful for areas like parking lots or locations where vehicles may stop for extended periods. Presence Mode ensures the gate doesn’t close prematurely, enhancing safety and preventing damage to vehicles.

Key Features

• Works with All Gate Opener Manufacturers: Compatible with any automatic gate system, making it a highly versatile solution.
• Wired Connection: Direct wired installation for reliable, interference-free vehicle detection.
• Multiple Detection Zones: High, medium, and low sensitivity detection zones ensure vehicles are detected at various distances.
• Secure and Durable: Features 128-bit AES encryption for secure communication and an IP68 waterproof rating for long-term outdoor durability.
• Multiple Mounting Options: Can be surface-mounted, flush-mounted, or concealed (concealed mounting for Exit Mode only).
• Low Power Consumption: Operates on 12-24VDC with minimal power draw during both standby and active modes.

Technical Specifications

• Input Voltage: 12-24VDC
• Relay Connections: NC/COM/NO
• Current: Standby 20mA, Active 30mA
• Ingress Protection: IP68 waterproof rating
• Mounting Options: Surface-mounted, flush-mounted, and concealed (Exit Mode only)
• Activation Zones: Varies by vehicle detection range (high, medium, and low sensitivity)

Product Variants

• EL00W: Exit Mode, standard wired vehicle loop for detecting vehicles leaving the premises.
• EL00W-RAD: Presence Mode with added radar protection, ideal for ensuring the gate remains open while vehicles are stopped above the loop, preventing premature closure on cars.

Q&A:

1. Does the EL00W require a transceiver?
   No, the EL00W is a wired system that connects directly to the gate control system via relays. It does not require a transceiver for operation.
2. Is the EL00W compatible with all gate opener systems?
   Yes, the EL00W is compatible with all gate opener manufacturers, making it a versatile solution for any automatic gate system.
3. What is the difference between Exit Mode and Presence Mode?
   Exit Mode opens the gate when a vehicle is leaving, whereas Presence Mode keeps the gate open as long as a vehicle is detected in the area, preventing premature closure and enhancing safety.
4. Can the EL00W be concealed for installation?
   Yes, the concealed mounting option is available but only for Exit Mode. This ensures a more discreet installation when aesthetics or space are a concern.
5. How does the IP68 rating benefit this system?
   The IP68 waterproof rating means the EL00W is fully protected against dust and can withstand long-term immersion in water, making it ideal for outdoor use in harsh conditions.

Conclusion

The EL00W offers an unparalleled combination of reliability, security, and versatility. Unlike wireless systems, the EL00W provides a hardwired solution that minimizes the risk of interference and signal loss. Its durable design ensures long-term operation even in the most demanding outdoor conditions. With surface, flush, or concealed mounting options - with the concealed setup dedicated to Exit Mode only - it offers flexible installation methods for various environments. Importantly, the EL00W is compatible with all gate opener manufacturers, making it easy to integrate into any existing automatic gate system.
