Doorking 6500-385 Secondary Swing Gate Operator - 1 HP

Secondary Heavy-Duty Swing Gate Operator for Dual Installations

The DoorKing 6500-385 is the secondary (slave) swing gate operator designed for use in tandem with the 6500-384 primary unit. Featuring the same powerful 1 HP continuous-duty motor, it delivers synchronized movement for dual gate configurations. Unlike the primary, this model does not include a control board and cannot function independently. It is purpose-built to work as a coordinated partner to the 6500-384, extending high-performance automation to both leafs of a swing gate system.

Key Features

• 1 HP continuous-duty motor matches the power and performance of the primary unit
• Slave operator design - requires 6500-384 primary operator to function
• Magnetic limit system ensures accurate and contact-free gate positioning
• Breakaway hub protects internal gears from damage during forceful impacts
• Dual-arm articulation delivers smooth motion across full gate travel
• Manual release allows emergency gate operation
• Steel frame with weather-resistant enclosure for reliable outdoor use
• UL 325 compliant when installed as part of a complete system

Technical Specifications

• Gate Capacity: Up to 22 ft and 800 lb per leaf
• Motor: 1 HP, continuous-duty, 115 VAC
• Control Board: Not included (requires 6500-384 primary unit)
• Limit System: Magnetic sensing
• Gearbox: 60:1 worm gear in sealed oil bath
• Power Type: AC
• Mounting Type: Pad-mounted
• Temperature Rating: 10°F to 115°F (-12°C to 62°C)
• Housing: Polypropylene split housing
• Compliance: UL 325, ETL Listed
• Compatible Primary: 6500-384

Conclusion

The DoorKing 6500-385 is the essential secondary operator for heavy-duty dual swing gate systems. It mirrors the robust design of the 6500-384 and enables synchronized, secure, and reliable gate movement when installed as part of a tandem configuration.
