All-O-Matic SW-350 DC "PRO" Swing Gate Opener - 1 HP

Heavy-Duty 1-HP Swing Gate Operator with Battery Backup and Quick Release

The All-O-Matic SW-350 DC PRO 1 HP automatic swing gate opener is a high-performance solution built to automate heavy-duty gates for residential, commercial, and industrial applications. This opener can handle gates weighing up to 2,500 lbs and stretching up to 22 feet, making it ideal for larger properties with substantial gate systems.

Powered by a 1 HP motor, the SW-350 DC delivers continuous duty cycles, ensuring reliable operation even in high-traffic environments. It features a battery backup system that keeps the gate functional during power outages, ensuring security and convenience. The SRA-RR300 Quick Release Arm enables manual gate operation when needed, and the system requires a monitored photoeye for safety and compliance with modern standards.

Key Features

• Supports Gates Up to 2,500 lbs and 22 Feet Long: Perfect for heavy-duty residential and commercial gates.
• Continuous Duty Cycle: Designed to withstand high-traffic environments.
• Battery Backup: Keeps the gate functional during power outages for uninterrupted operation.
• SRA-RR300 Quick Release Arm: Allows for quick and easy manual operation in emergencies.
• Monitored Photoeye Requirement: Ensures safe operation by detecting obstructions.
• All-Weather Performance: Operates reliably in extreme temperatures from -40°F to 160°F.

Technical Specifications

• Max Gate Weight: 2,500 lbs
• Max Gate Length: 22 feet
• Motor Power: 1 HP DC motor
• Power Supply: 24 VDC with built-in battery backup
• Gate Speed: 19 seconds for a 90-degree opening
• Emergency Release: SRA-RR300 Quick Release Arm and foot pedal
• Monitored Photoeye Requirement: One monitored photoeye required for operation
• Temperature Range: -40°F to 160°F
• Duty Cycle: Continuous

Conclusion

The All-O-Matic SW-350 DC 1 HP swing gate opener is engineered for maximum power and reliability. With the ability to handle gates weighing up to 2,500 lbs, this operator is ideal for large, heavy-duty applications. Its battery backup ensures the gate remains functional even during power outages, and the quick release arm provides manual control when necessary. Additionally, the inclusion of a monitored photoeye ensures compliance with modern safety standards, making it a top choice for residential, commercial, and industrial properties alike.
