FAAC 400 (EG) Repair Parts
We carry repair and replacement parts for the FAAC Model 400 (EG) elongated hydraulic swing gate operator. If your part is not listed below, enter the part number in the search bar at the top of the site. Need help identifying a hydraulic component? Send our parts team the part number or a description and we'll find the right replacement.
Parts list
26 items
1
FAAC 4994655 Distribution Flange for FAAC 400
2
FAAC 63003327 Retract Tube and Tie Rods EG
3
FAAC 4404085 Lock Valve for FAAC Hydraulic Operators
4
FAAC 4180285 Shuttle Piston
5
FAAC 4350115 Piston Assembly 400 Riveted EG
6
FAAC 4994625 Front Flange
7
FAAC 63000315 Front Flange Seal
8
FAAC 4180195 Manual Release
9
FAAC 4404065 Inlet Valve
10
FAAC 4180415 Bypass Cap
11
FAAC 4404095 Bi-Directional Inlet Valve
12
FAAC 4185045 Locking Cap Manual Release Kit
13
FAAC 7290445 Manual Release Knob w/ Screw
14
FAAC 7131005 Manual Override Key For 400 Model
15
FAAC 4900645 Rear Mounting Bracket Kit for 400 & 402
17
FAAC 7110015 Oil Plug
21
FAAC 70991015 Gasket D80 Seal for 400, 402, 422 Models
22
FAAC 3204445 Cast Iron Pump Lobe 1.5 Lt
24
FAAC 2167.1 Seal Kit for 400 CBC Operators
25
FAAC 7220365 Front Mount Bracket for 400 EG Operators
26
FAAC 63003329 Protective Cover for FAAC 400EG
27
FAAC 7073095.1 Swivel Joint Kit
28
FAAC 714019 Hydraulic Oil for Gate Operators (1 Qt)
29
FAAC 2705 Capacitor for FAAC Swing Gate Operators - 115V
30
FAAC 77000425 Motor for Swing Gate Operators - 115V
31
