Doorking 9402-045 Loop Detector

Doorking 9402-045 Loop Detector (12/24Vdc or 24Vac)

DKS 9402-045 is a loop detector 12/24Vdc or 24Vac. Harness not included. For use with various DoorKing® gate operators. The Model B is a full featured, single channel, dual output vehicle detector that incorporates the reliable vehicle detection technology.

Features

• 12/24Vdc or 24Vac
• 11 pin harness required
• Eight levels of sensitivity.
• Sensitivity Boost for applications where high-bed vehicles might be encountered.
• Detect Memory feature maintains detection during momentary power interruptions of up to two seconds.
• Fail LED indicates current loop failures or loop failures that have occurred.
• Four loop frequencies.
• Loop Fail Memory stores a record of the last loop failure.
