Linear Juno Slide Gate Operator - Compact & Solar Ready
Linear Juno Slide Gate Operator - Compact & Solar Ready is backordered and will ship as soon as it is back in stock.
Core Details
| Product Type | Slide Gate Operator |
| Application Type | Gate |
| Installation Type | Residential | Commercial |
| Voltage | 115V | 12V |
| Power Type | AC | Solar |
| Mounting Type | Pad Mounted |
| Mechanism Type | Chain Drive |
| Motor Type | DC Motor |
| Horsepower (HP) | 0.5 HP |
| Battery Backup | Included |
| UL/ETL Certification | Yes |
| Max Gate Weight | 800 Lbs |
| Max Gate Length | 40 Ft |
| Phase | Single-Phase |
| Chain Size | #40 |
| Solar Ready | Solar Ready |
| Weatherproof Rating | Rated for Outdoor Usage |
| Operating Temperature | -4° to 122°F |
Linear Juno Slide Gate Operator - Compact & Solar Ready
Description
Description
Compact Slide Gate Operator with Integrated Lighting and Photo Eyes
The Linear Juno is a compact yet powerful slide gate operator designed for residential and light commercial use. With the strength to move gates up to 800 pounds and 40 feet long, it combines a rugged UV-stabilized enclosure with high-end features like a built-in driveway light, integrated reflective photo eyes, and a red/green status indicator for enhanced visibility and user feedback. Equipped with the Mercury 310 controller, the Juno simplifies installation and supports both AC and solar applications with intelligent battery management.
Key Features
- Smooth Performance – Opens gates up to 40 ft and 800 lbs at 1 ft/sec
- Integrated Photo Eyes – One internal and one external BlueBUS reflective photo eye reduce clutter
- Built-in Driveway Light – Illuminates the gate area during operation and for 20 seconds after
- Red/Green Status LED – Provides visual feedback during gate motion
- Mercury 310 Controller – Simplified, intuitive setup with integrated charger and UL 325 entrapment protection
- Lockable Manual Release – Allows secure manual operation when needed
- Durable UV-Stabilized Enclosure – Weather-resistant housing for long-term performance
Technical Specifications
- Maximum Gate Weight: 800 lbs
- Maximum Gate Length: 40 ft
- Gate Speed: 1 ft/sec
- Operating Voltage: 12VDC
- Input Power: 12VDC (AC or Solar Compatible)
- Temperature Range: -4° to 122°F (-20° to 50°C)
- Idle Current: 10 mA
- Accessory Power: Regulated 12VDC 500 mA (always on and standby)
- Communication: BlueBUS, USB, OXI
- Controller: Mercury 310 with MMPT solar support and battery charger
- Enclosure Size: 17.2" W x 16" H x 10.8" D
- Finish: Molded UV-stabilized cover
- Compliance: ETL Listed, UL 325, Class I & II
- Warranty: 3 Years with product registration
What's Included
- OXIBD/A receiver
- (2) ON2E/A transmitters
- (1) external BlueBUS reflective photo eye
- (1) internally mounted BlueBUS reflective photo eye
- Built-in driveway light
- 30 ft of #40 corrosion-resistant chain
Conclusion
The Linear Juno operator is a compact, installer-friendly, and feature-rich solution for residential and light commercial sliding gates. With solar readiness, integrated safety features, and clean aesthetics, it delivers reliable performance and streamlined installation that meets modern perimeter security demands.
